| DIMENSIONS |
Length (mm) |
4360 (14'4") |
| Width (mm) |
1430 (4'8") |
| Height (mm) |
1450 (4'9") |
| Full Extending Height (mm) |
9 (29'6") |
| Gross Weight (kg/lbs) |
980 (2160 lbs) |
910 (2010 lbs) |
| ENGINE |
Engine |
D1105 (KUBOTA) |
Z482 (KUBOTA) |
| Rotational Speed (rpm) |
1500/1800 |
3000/3600 |
| Number of Cylinder |
3 |
2 |
| Engine Character |
4cycle, watercooled diesel |
| Combustion System |
E-TVS |
| Engine Aspiration |
Naturally Aspirated |
| Emission Level |
Regular |
| ALTERNATOR |
Standard Configuration |
SPARKS |
| Frequency (Hz) |
50/60 |
| Rating Voltage |
230/240-120VAC |
| Alternator Insulation |
Class H |
| Alternator Protection Grade |
IP 23 |
| MASS & LIGHTS |
Type of Light |
Double end Metal Halide |
LED |
| Light's Fixture |
Oval |
Rectangle |
| Luminous Flux |
165000 |
390000 |
| Number & Power of Lights (W) |
4 x 1500 |
4 x 3000 |
| Number of Mast Section |
3 |
| Mass Lifting |
Manually |
| Mast Extension |
Manually |
| Mass Rotation |
Manually, Max 330 lockable |
| Light Tilt |
Manually |
| TRAILER |
Trailer Suspension & Axle with Brakes |
Leaf springs & single axle with brakes |
| Tow Bar |
Retractable & Adjusting Supporting Wheel Tow Bar |
| Stabilizing Legs & Number |
4pcs Extendable Bar with Manually Retractable Jack |
| Wheel's Rim Size & Tires |
14" Rim with Regular Tires |
| Tow Adapter |
2" or 5 ball adapter |
| Tail Lights |
Tail Reflector |
| Max Towing Speed (km/H) |
100 (62mph) |
| ADDITIONAL FEATURES |
Fuel Tank Type |
Rotational Moulding Plastic |
| Fuel Tank Capacity (L) |
170 |
| Operating Hours (hours) |
80 |
360 |
| Wires & Electric Components |
Regular |
| Generator Starting Type & Controller |
Key Starting |
| Max Againts Wind (m/s) |
20 (45mph) |
| Accoustic Pressure |
72db (A) at 7 meters away |
